M6FTY-10 Small Scale Flour Mill Machinery
With
the development of word economy and acceleration of circulation of grain, the new situation of grain processing have been taken on and small scale, low investment flour mill have been welcomed by the vast village. So our flour mill machinery designed a new and small scale unit which can meet the demand of the current market.
M6fty-10 series flour mill machinery all scale unit with low investment and high efficiency, but a complete set of equipment which can produce
continuously.
Main Technical Data
- Output:10Tgrain within 24hous
- Extraction flour: when the quality of the grain confirm the stipulation of China GB1351-86(the volume weight is over (770g/l) F1 flour:60% F2 flour:70% Standard flour:78%
- Quality of the flour: conform the stipulation of China GB1355-86
- Total power: 26.5kw,3 phase,380v,50hz
- Water content: add 2-3 percent water to the grain according to the water content of raw material
- The covering area:6.6*3.8*3.5m
- The tempering tank includes two parts,the size of each tank is: 0.9*1.5*1.5m
| No | Name | Model | Qty |
| 1 | Flour milling machine | 6fy-35 | 2 |
| 2 | Fan | 6-23no-5c | 1 |
| 3 | Fan | 8-18no-4a | 1 |
| 4 | Reel separator | No30 | 4 |
| 5 | Stoner | Qs-40 | 1 |
| 6 | Scourer | 6nf-90 | 2 |
| 7 | Air lock | Gfy-150 | 4 |
| 8 | Sliding separator | 1 | |
| 9 | Auger | 150*1000 | 1 |
| 10 | Scourer | 20 | 1 |
